RF4 360 Rotating Vacuum LCD Screen Separator Machine

360 Rotating LCD Separator Machine for Clean Screen Separation

The RF4 360 rotating LCD separator machine gives your workflow a dedicated heated station for separating glass, touch screens, and LCD assemblies. Its table rotates freely, so you can reach every edge of a phone without repositioning the device by hand. The built-in vacuum pump grips the assembly during the process, and the heating surface softens the adhesive so you can work with less force. Read on to see where this machine fits in your bench routine and how to use it step by step.

Where This Machine Fits in Your Screen Repair Workflow

Most screen replacement jobs follow the same sequence: remove the frame, split the cover plate from the LCD, clean the adhesive, and reassemble with fresh glue. This machine covers the middle stages of that sequence. You use it when the cover glass and LCD need to come apart cleanly, and you use it again when you clean the frame edges before the new screen goes in. If your bench handles frequent flat-screen jobs and curved-edge jobs, one station that handles both saves setup time between repairs. It works best as the center of your separation process rather than a backup tool.

Rotation and Fixtures for Curved Screens

Curved-edge phones are where most separation mistakes happen, because the glass pulls unevenly along the frame. The 360-degree rotating table lets you turn the device to the angle that gives you the cleanest cut line, and it keeps going without any dead spot. The rotating fixture for the curved middle frame keeps the phone stable while you work along the curve. A detachable fixture lets you swap setups without tearing down the whole station. Together, these parts reduce the amount of hand pressure you need on delicate edges.

Vacuum LCD Screen Separator Heating and Control

The heating table runs from 0 to 150°C, so you can match the temperature to the adhesive on the phone in front of you. Set the temperature before you place the middle frame on the workbench, and let the surface reach the target before you start the separation. The vacuum switch holds the assembly flat during heating, which keeps the screen from shifting while the glue softens. The adjustable tilt angle lets you position the device at a comfortable height and angle for long sessions. Keep the temperature moderate for each job, because excess heat can stress the display.

Step-by-Step Separation Workflow on Your Bench

Power on the machine and set your target temperature first. Place the middle frame on the workbench and open the vacuum switch to secure it. Remove the frame before you split the cover plate, then cut the top edge of the screen with an OCA thin slice. Swipe a blade along both sides of the screen to loosen the adhesive. Turn the device over and use the OCA slice to split the screen fully. Clean the screen edge glue and adjust the screen direction. Insert the thin slice at the cover edge to open a positioning port for the steel wire. Work the separating rod from one corner, then move to the opposite corner to keep the separation balanced. Exhaust the vacuum and lift the screen free.

Compatibility, Package, and Practical Limits

This machine supports LCD separation for iPhone, Samsung, Xiaomi, and other mobile phones, with both flat and curved LCD assemblies in scope. The package includes one separator machine and one power cable, so you need a compatible bench outlet and your own separation tools, such as OCA slices, blades, and a steel wire. Confirm the screen size of each job before you start, because the working surface suits phones up to the size stated on your product listing. For brands and models outside iPhone, Samsung, and Xiaomi, treat the compatibility as general and test on a spare screen first. A consistent process on this station gives you cleaner separations and fewer broken screens at the end of each day.
